IPXM62-T
Technical Parameter
60A WITH NHF
60% DUTY CYCLE
4.5-5.0 BAR
120-130L/min
60s POST FLOW
18mm(500mm/min)RECOMMENDED VALUE
Procurement code
MVT33071
6M
1/4G Pneumatic-electric Integggrated/back striking
MVT33072
6M
1/4G Gas electric Separation/back striking
MVT33073
6M
Central Adapter/back striking
MVT33074
6M
Central Adapter/Coaxial
Consumables procurement code(with”🔴”is the standard configuration)
| Position | Code | Ref. | Description |
|---|---|---|---|
| 0 | MVG0654 | Torch head kit | |
| 🔴1 | MSM0652 | CV0157 | |
| 2 | MSM0675 | CV0125 | |
| 🔴3 | MSM0658 | CV0153 | |
| 🔴4 | MVS0632-05 | PC0187-05 | Glass fiber | 5.1 | MVU0792-08 | PD0247-08 | Φ0.8mm 30A |
| 5.2 | MVU0792-09 | PD0247-09 | Φ0.9mm 40A |
| 5.3 | MVU0792-10 | PD0247-10 | Φ1.0mm 50A |
| 🔴5.4 | MVU0792-11 | PD0247-11 | Φ1.1mm 60A |
| 6 | MVU0756 | PD0251 | 30-60A Gouging |
| 🔴7 | MVF0052 | PE0057 | |
| 🔴8 | MVB1048 | PR6093 | |
| 9 | MVZ0720 | ||
