IPTM100-T
Technical Parameter
100A WITH NHF
60% DUTY CYCLE
4.5-5.0 BAR
200L/min
100s POST FLOW
25mm(500mm/min)RECOMMENDED VALUE
Procurement code
MVT33061-00
6M
1/4G Pneumatic-electric Integggrated/back striking
MVT33062-00
6M
1/4G Gas electric Separation/back striking
MVT33063-00
6M
Central Adapter/back striking
MVT33064-00
6M
Central Adapter/Coaxial
Consumables procurement code(with”🔴”is the standard configuration)
| Position | Code | Ref. | Description |
|---|---|---|---|
| 0 | MVG0619 | Torch head kit | |
| 1 | MSM1064 | 60508 | Gouging |
| 2 | MVS1678-05 | 60500 | Glass fiber 30-70A | 🔴3 | MVS1676-05 | 60501 | Glass fiber 80-120A | 4 | MVS1674-05 | 60502 | Contact | 5.1 | MVU1678-10 | 51246.10 | Φ1.0mm 50A |
| 5.2 | MVU1678-11 | 51246.11 | Φ1.1mm 60A |
| 5.3 | MVU1678-12 | 51246.12 | Φ1.2mm 70A |
| 6.1 | MVU1676-14 | 51248.14 | Φ1.4mm 90A |
| 6.2 | MVU1676-15 | 51248.15 | Φ1.5mm 100A |
| 🔴6.3 | MVU1676-16 | 51248.16 | Φ1.6mm 100-120A |
| 7 | MVU1687-22 | 51248G.22 | Φ2.2mm 120A Gouging |
| 8 | MVF1662 | 60025 | 30-70A |
| 🔴9 | MVF1661 | 60026 | 80-120A |
| 🔴10 | MVB1676 | 52556 | |
| 🔴11 | MZN0774 | FH0229 | |
| 12 | MVZ0722 | ||
